Epcom
Showing all 12 results
-
Epcom Camera
Epcom 15x Zoom PTZ 2MP IP
- 1/2.8″ CMOS Sensor With High Sensitivity for Low Light Performance
- 5-75 mm Motorized Lens With 15X Optical Zoom Capability
- EXIR Infrared Technology Provides Clear 328 ft Night Vision
- 120 dB Wide Dynamic Range for Extreme Backlight Conditions
- H.265+ Compression Reduces Bandwidth Usage up to 80%
SKU: n/a -
Epcom DVR
Epcom 16 Channel 1080p
Features:
- TURBOHD technology 1080P Lite Ver. 3.0
- Support 5 technologies TVI / CVI / AHD / Analog / IP
- Support 16 channels TURBOHD / analog + 2 channels IP = 18 channels in total.
- 1 Audio Input / 1 Audio Output (RCA connector).
- Support compresion H.265+ / H.265 / H.264+ / H.264.
- Compatibility with Internet Explorer / Chrome (ietab).
- Capacity for 1 SATA 10 TB HDD.
- Video HDMI / VGA Simultaneous output Full HD 1080p.
- Supports DDNS Hikvision Service.
- Supports P2P Hik-Connect.
- Compatible with client software iVMS-4200 (Windows, IOS), Hik-Connect (Android, iPhone, iPad, iPod Touch).
Video Channels:
- HD-TVI: 1080p Lite / 720p@ 12 IPS.
- CVBS: WD1@ 30 IPS.
- AHD: 1080p Lite / 720p@ 12 IPS.
- CVI: 1080p Lite / 720p@ 12 IPS.
- IP: 5 Megapixel
- BNC Connector.
Video Coding:
- Main stream: 1080P Lite / 720p / WD1 / VGA / 4CIF.
- Sub stream: CIF / QCIF
- Bitrate: 32 Kbps up to 6 Mbps.
Video Output:
- Video de HDMI and VGA simultaneous output.
- Supported Resolutions: 1920 x 1080 / 1280 x 1024 / 1280 x 720 / 1024 x 768.
Recording:
- Recording with automatic overwriting.
- Configurable to start recording with only one click.
- Recording programming through calendar, manual, or event.
Search and Playback:
- Instant playback of a camera in live Multi-Vista mode.
- Simultaneous synchronous 4-channel playback at 1080p Lite in forward/backward.
- Local and remote playback, with log or event search.
- Recording Identification through tags and playback through tags.
- Important segment block to avoid overwriting.
Events:
- Audible alert, Pop-Up, e-mail notification, and notification to the monitoring center when an event is triggered.
- Movement detector alarm, camera block, and disconnection, configurable by channel.
- Monitor HDD status, network, entries, and camera status with remote notifications.
Network:
- 6 simultaneous users.
- Supports Main and Sub Stream.
- Supported Protocols: TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP, HTTP, HTTPS.
Interface:
- 1 Network Port: RJ-45 10/100 Mbps.
- 2 USB 2.0 Ports (Supports Mouse, included).
Physical and Electrical Characteristics:
- Power Supply: 12 Vcc (Included)
- Consumption: Max. 8 W.
- Operating Temperature: 14 ~ 131°F (-10 ~ 55 ºC).
- Dimensions: 7.87 x 7.87 x 1.77″ (200 x 200 x 45 mm).
- Weight: 1.76 lb (800 g).
SKU: n/a -
Epcom DVR
Epcom 16 Channel 5mp/3k
- Pentahybrid Support for HD-TVI, HD-CVI, Analog, IP, and AHD Camera Formats
- H.265+ Compression for Efficient Storage and Bandwidth Optimization
- Bi-Directional Audio Over Coaxitron Technology on All Channels
- 4-Channel Facial Recognition Capability With TurboHD Cameras
- AcuSense Technology Filters False Alarms From Animals and Debris
SKU: n/a -
Epcom Camera
Epcom 25x Panaramic PTZ 4MP IP
- Dual 4MP Cameras With Panoramic View and PTZ Functionality
- Smart IR Night Vision With Automatic Adjustment up to 328 ft
- Advanced Detection Features: Face Recognition and Intrusion Detection
- H.265+ Compression Reduces Bandwidth and Storage Requirements
- 360° Pan and 90° Tilt With 300 Preset Positions
SKU: n/a -
Epcom Camera
Epcom 2MP ColorVu Audio Bullet Camera
- Minimum Illumination 0.001 Lux for Superior Low-Light Performance
- 105° Wide Viewing Angle With Fixed 2.8 mm Lens
- Built-in Microphone for Audio Recording Capability
- Advanced WDR, BLC, and HLC for Optimal Image Quality
- Wide Operating Temperature Range -40°F to 140°F
SKU: n/a -
-
Epcom NVR
Epcom 32 Channel NVR 12MP
Features:
- Compression: H.265, H.264+, H264, MPEG4.
- 32 recording channels.
- Throughput (Processing level on input / output):
- Input processing: 320Mbps (200Mbps / RAID active).
- Output processing: 256Mbps (200Mbps / RAID active).
- Remote access via cellphone platforms iPhone, iPad (ask for compatible models).
- Multi-browser compatibility, Firefox, Safari, IE, applies for all models of 16, 32 and 64 channels.
- Multi-site client software of up to 64 channels (IVMS4200).
- Remote firmware update.
Recording and Playback Function
- Multi-zone movement detection
- Digital zoom in playback and recording
- Supports multiple types of recording including, real-time, manual recording, video sensor, external alarm, video sensor and alarm, video sensor or alarm.
- Smart search for recording through movement detection.
- DVD and CD burner (OPTIONAL).
Interfaces Inputs / Outputs:
- HDMI x 2:
- HDMI 1: 4K (3840×2160), 2K (2560×1440), 1920×1080, 1600×1200, 1280×1024, 1280×720, 1024×768.
- HDMI 2: 1920×1080, 1280×1024, 1280×720, 1024×768.
- VGA x 2:
- VGA 1: 2K (2560×1440), 1920×1080, 1600×1200, 1280×1024, 12080×720, 1024×768.
- VGA 2: 1920×1080, 1280×1024, 1280×720, 1024×768.
- AUDIO INPUT: 1 Channel (RCA, 2.0 Vp-p, 1KΩ).
- AUDIO OUTPUT: 2 Channel (RCA, 2.0 Vp-p, 1KΩ).
- ALARM INPUT: 16
- ALARM OUTPUT: 4
- SERIAL INTERFACE: RS-232 / RS-485 / KB (Keyboard).
- USB INTERFACE:
- Frontal panel: 2 port 2.0
- Rear panel: 1 port 3.0
- WEB INTERFACE: 2 ports (RJ-45 10/100/1000 Mbps).
- EXTERNAL RECORDING: 8 Servers NAS or 7 NAS+1SCSI.
- SATA HDD CAPACITY: 8 HDDs / 6TB per disk.
- e-SATA INTERFACE: 1 e-SATA port
- HDD ARRANGEMENT: 4 (RAID0, RAID1, RAID5, RAID10).
Physical and Electrical features
- Approved by: FCC, UL, CE, CB, CCC, SGS.
- Chassis: Rack mounting 19″, 2UR
- Operating temperature: -10 ~ 55ºC.
- Power supply: 100 ~ 240 VCA, 50 ~ 60Hz.
- Maximum electrical consumption: 200W.
- Dimensions: 445 x 470 x 90mm.
- Weight: 10 Kg. (without hard drives).
SKU: n/a -
Epcom Camera
Epcom 5MP Audio ColorVu Metal Bullet
Main Features:
- Maximum resolution: 3K (5 Megapixel) (2960 x 1665)
- Minimum illumination: 0.001 Lux @ (F1.0, AGC ON)
- Fixed lens: 2.8 mm (aperture angle 102°)
- 20 Meters of white light (helps illuminate the site to keep the image always in color).
- Supports 4 Technologies, selectable in cable harness (HD-TVI, HD-CVI, AHD, CVBS Analog 1200TVL´s)
- dWDR
- Built-in microphone
SKU: n/a -
Epcom Camera
Epcom 5MP Audio Metal Bullet
Main Features:
- Resolution: 5 Megapixels (2560 x 1944)
- Allow selecting the resolution between 5 Megapixels / 4 Megapixels / 2 Megapixels.
- Minimum Ilumination: 0.01 Lux @ (F1.2, AGC ON, 0 Lux con IR.
- Lens: 2.8 mm (FOV 85º).
- 30 m SMART IR EXIR (night vision).
- Support 4 technologies (TVI / AHD / CVI / CVBS ).
- Functions: dWDR / BLC / AGC /2D DNR.
SKU: n/a -
Epcom DVR
Epcom 8 Channel 1080p
Main Features:
- TURBOHD 1080P Lite Technology.
- Support for 5 technologies: HD-TVI / Analog / HD-CVI / AHD / IP.
- Remote access: PC (WINDOWS / MAC), Smart Phone (iPhone, iPad, Android).
- Compatibility with Chrome browser (IE tab), Safari, Internet Explorer.
- Multi-site client software for up to 256 channels (iVMS-4200).
- Compatible with Hik-Connect P2P (https://appstore.hikvision.com/).
- Supports DynDNS / No-IP.
Compression and Resolution:
- H.265 Pro+ / H.265 Pro / H.264+ / H.264.
- Supports 8 TURBOHD / analog channels + 2 IP channels = 10 channels in total.
- NOTE: Allows turning off analog channels to add IP channels.
- Supports technologies:
-
- HD-TVI: 1080p Lite / 720p@ 30 IPS.
- CVBS: WD1 @ 30 IPS.
- AHD: 1080p Lite / 720p @ 30 IPS.
- CVI: 1080p Lite / 720p @ 30 IPS.
- IP: 5 Megapixel.
- Audio is received through the TVI signal.
- Equipped with AcuSense to filter humans and vehicles through motion detection (Does not include video analytics such as line crossing / area entry).
SKU: n/a -
Epcom DVR
Epcom 8 Channel 5mp/3k DVR
- Hybrid Support for HD-TVI, HD-CVI, Analog, IP, and AHD Camera Formats
- H.265+ Compression Technology for Maximum Storage Efficiency
- Simultaneous HDMI and VGA Video Output for Multiple Displays
- Remote Access via PC, Mac, iOS, and Android Mobile Devices
- Supports up to 10 TB Hard Drive for Extended Recording Capacity
SKU: n/a -
Epcom DVR
Epcom 8 Channel 8MP
Main Features:
- It allows you to turn off analog TURBOHD channels and be able to place IP cameras on all your channels, we can place up to 32 IP cameras in total. An additional IP channel is generated for each TURBOHD analog channel that is turned off.
- PENTAHÍBRIDO recorder: HD-TVI / HD-CVI / Analog / IP / AHD.
- Multi-site client software with up to 64 channels (iVMS-4200).
- Compatible with Hik-Connect P2P / DynDNS / No-IP.
- Advanced Functions: Line crossing detection & intrusion detection.
Compression and resolution:
- Compression: H.265+ / H.265 / H.264+ / H.264.
- Supports 16 channels TURBOHD / analogs + 16 IP channel = 32 total channels.
- HD-TVI: 8 MP @ 8fps / 5 MP @ 12fps / 4 MP @ 15fps / 3 MP @ 18fps / 1080p / 720p.
- CVI: 5 Megapixel / 4 Megapixel / 1080p / 720p.
- ANALOG (CVBS): 1200 TVL.
- AHD: 5 Megapixel / 4 Megapixel / 1080p / 720p.
- IP: 8 Megapixel.
SKU: n/a
