Camera Accessories / CCTV Power Supplies

General characteristics:

• 30-micron gold plating for the best performance.
• No shielding
• 24 AWG.
• Easy installation.
• Excellent performance.

General characteristics:

• 30-micron gold plating for the best performance.
• No shielding
• 23 AWG
• Easy installation.
• Excellent performance

Applications:

• Video surveillance cameras.

Features:

• Input voltage: 100-240 Vac.
• High efficiency.
• Surge and short circuit protection.

Technical specifications:

• Input voltage: 100 V to 240 Vac
• Input current: 0.8 A
• Output Voltage 12 Vdc
• Output current: 2 A
• Frequency: 50-60 Hz
• Operating temperature: -20°C – 45°C
• Dimensions: 71.4 x 45.3 x 37.7 mm

• Easy installation
• Short circuit and over-voltage protection.
• Conventionally cooling system air.
• External LED indicators for each channel output.
• Built against electromagnetic interference filter EMI.

Protection:
• Overcurrent protection: 105 ~ 150% (rated output voltage)
• Overvoltage Protection: 1.5 times of the rated voltage
• Short circuit protection: short the output voltage, with automatic reset.

Physical and Electrical Specifications:

• Approved by: IEC / EN / UL / CSA, 60950 GB4943
• Input voltage: 100 o 240 Vac
• Output voltage: 11.5 ~ 15 VDC. (adjustable)
• Output Current: 30 A

• Output Current by channel : 2.5 A
  • Board distribution: 1 for connection of 18 cameras.
  • Dimensions: 10.43 x 10.03 x 3.14″
  • Operating temperature: -14 ~ 122 °F
  • Weight: 5.5 lb

For 4K Cameras

• Easy installation
• Short circuit and over-voltage protection.
• Conventionally cooling system air.
• External LED indicators for each channel output.
• Built against electromagnetic interference filter EMI.

Protection:

• OCP Over Current Protection
• OVP Over Voltage Protection
• SCP Short Circuit protection

( More information in the datasheet )

Physical and Electrical Specifications:

• Approved by: IEC / EN / UL / CSA, 60950 GB4943
• Input voltage: 110 ~ 220 Vac
• Output voltage: 11.5 ~ 15 VDC. (adjustable)
• Output Current: 20 A
• Board distribution: 1 for connection of 16 cameras.
• Dimensions: 10.33 x 3.14 x 10 in.
• Operating temperature: -14 ~ 122 °F
• Net weight: 4.40 lb (2.450 Kg).

Features:

• 1080P HDMI and HDCP.
• HDMI output for local monitoring screen.
• Range of 50 m  HDMI to CAT5 / 5e / 6 cable.
• Extensor and divide by LAN (delivered by the router/switch) for cascade connection.
• IR pass-through to control the source device to a secondary location.
• Compatible with the existing network, does not affect the Internet
• Plug and play without any manual adjustment.
• HDMI HDCP signal
• Resolutions: 480i @ 60Hz, 480p @ 60Hz, 576i @ 50 Hz, 720p @ 50 / 60Hz, 1080i @ 50/60 Hz, 1080p @ 50/60 Hz
• Network Cable: UTP Cat5 / 5e / 6
• Transmission distance: 120 meters / 394 feet for 1080p Full HD
• IR signal: Supports devices 20-60 KHz.

• No power supply required.
• Dimensions: 38.4(L) x 18.6(W) x 19.5(H) mm (BNC connector and cable excluded).
• Weight: 22 grams.
• Operating temperature: -20°C to 70°C.
• Storage temperature: -40°C to 150°C.
• Relative humidity: 0~95% (non-condensing).
• ABS casing.
• Color: Black.

Applications:

• CCTV monitoring and recording Systems

Features:

• 200 meters @ 5 MP
• 150 meters @ 4 K

• Transceivers active kit TurboHD

• Real-time transmission cable UTP cat 5e / 6

• Transmission power 12 V / 24 Vdc / Vac

• Compatible video formats NTSC, PAL, SECAM

• Compatible with analog cameras: HD-TVI, HD-CVI, and AHD

• BNC male connectors

• Pin type terminals for UTP

• Built-in Surge Protection

• Wave filter design antistatic

• Noise Immunity 60 dB

• Impedance 75 Ω

• Color: Black

• Operating temperature: -4 to 158°F (-20 to 70 °C)

• Dimensions (L x W x H): 2.37 x 1.14 x 0.80″ (60.4 x 29 x 20.4 mm)

• Weight: 0.13 lb (60 g)

Pack of 100 Pieces
